Maximize Adhesive Efficiency with Precision Control
Experience unparalleled accuracy in glue dispensing with RTSTEC's advanced 3-axis control system, designed to meet the demanding needs of high-volume production environments.
Robust Design and Versatile Applications
This machine not only offers precise glue application but also ensures durability and adaptability across various industries including electronics, automotive, and packaging.
What is an adhesive dispensing robot
Automated Robotic Dispensing Systems are cost-effective solutions designed to simplify the dispensing of adhesives and sealants onto various surface configurations, ranging from simple to complex. Dispensing robots allow manufacturers to repeatedly and reliably dispense patterns of liquid materialson a programmed basis, resulting in improved process efficiencies, minimal material waste, and reduced manufacturing costs. Automated robotic dispensing systems are offered in multiple configurations to meet all your process needs.Features1, This Glue Dispensing Robot is a Simple and convenient operation, with high speed and precise control. Replace human labor and save labor costs.2, Automatic glue dispenser machine is to spray or dispense the glue automatically for bonding, filling, coating, sealing, filling, dripping, linear/arc/round coating, etc.3, Replace human labor and save labor costs. Realize the precise dispensing by the high-precision motor.4, Applied on Fluid sealant, Grease, Silver glue, Instant Adhesive, Thermal paste, Silicone glue, UV glue, Epoxy glue, Conformal Coating, SMT Adhesive, Solder paste, Threadlocker, Syringe glue, Paint etc.5, 1-year Warranty, Lifespan Technical Support. Contact us for further inquiries.
Parameters
|
Model
|
RTS-5531D
|
|
Dispensing Control
|
Dispensing Control System
|
|
Dispensing Speed
|
According to customer's product requirements and glue types
|
|
Maximum Load Weight
|
8kgs (for work platform)
|
|
Operation Range (X*Y*Z) (mm)
|
500*500*100mm
|
|
Axis
|
3 Axis (X,Y,Z)
|
|
Maximum Speed
|
X,Y 500mm/S, Z 300mm/S
|
|
Repeated precision
|
X,Y,Z ±0.02mm
|
|
Teaching Method
|
Remote Teaching/Manual Data Input/Optional: LCD Touch Screen
|
|
Motor system
|
precision stepper motor
|
|
Transmission mode
|
Precision Stepping Motor+Timing belt
|
|
Control Panel
|
Teach pendant (optional:PC or Touch Screen)
|
|
Voltage
|
AC 110V/220V,50Hz/60Hz
|
|
External Interface
|
USB + RS232
|
|
Power Source
|
Electricity + Pneumatic
|
|
Air pressure requirement
|
0.4 to 0.6MPa (4 to 6kg/cm2) as dry air
|
|
Dimension (L*W*H) (mm)
|
650*630*680mm
|
|
Weight(kg)
|
50 KG
|
|
Working Temperature
|
10-40C°
|
|
Working Humidity
|
20-90% RH
|
Dispensing Rounting Could be Edited . Operated by Teach Pandant
Applied On Many industrial Products
